Turbo Lamik TCU Error Code List
A place to check out what each of the error codes mean for the TurboLamik TCU.
| Error Code | Cause |
| 1 | No connection Solenoid Out1 (open circuit) pin86 |
| 2 | No connection Solenoid Out2 (open circuit) pin 84 |
| 3 | No connection Solenoid Outs (open circuit) pin83 |
| 4 | No connection Solenoid Out4 (open circuit pin78 |
| 5 | No connection Solenoid Out5 (open circuit) pin79 |
| 6 | No connection Solenoid Out6 (open circuit) pin7 6 |
| 7 | No connection Solenoid Out7 (open circuit) pin87 |
| 8 | No connection Solenoid Out8 (open circuit) pins 1 |
| 9 | No connection Solenoid Out9 (open circuit) pin82 |
| 10 | No connection Solenoid Out10 (open circuit) pin77 |
| 11 | No connection Solenoid Out11 (open circuit) pin80 |
| 12 | |
| 13 | Power Ground not connected, check in parameters "Ground differential voltage ", cannot be greater than 2V |
| 14 | Supply voltage too low |
| 15 | |
| 16 | Internal power supply fault, Short to ground |
| 17 | No RPM signal Gearbox Speed Sensor 1 pin 72 |
| 18 | No RPM signal Gearbox Speed Sensor 2 Pin 71 |
| 19 | No engine RPM signal |
| 20 | Open circuit or Short to ground of the Gearbox Speed Sensor 1 Pin 72 |
| 21 | Open circuit or Short to ground of the Gearbox Speed Sensor 2 Pin 71 |
| 22 | Open circuit or Short to ground of the Engine speed sensor |
| 23 | Inconsistency of the engine speed with the rotation of the gearbox input (Gearbox Speed Senso 1) possible slippage lockup |
| 24 | |
| 25 | Pressure sensor, signal too low or Short to ground |
| 26 | Pressure sensor, signal too high or Short circuit to plus |
| 27 | Pressure sensor, pressure too high relative to the atmosphere |
| 28 | Pressure sensor, pressure too low to atmospheric |
| 29 | Pressure sensor, no signal change |
| 30 | Throttle sensor signal error (TPS) |
| 31 | Oil temperature sensor error in the gearbox, possible open circuit |
| 32 | Can1 ERROR No Message |
| 33 | Can2 ERROR No Message |
| 61-104 | Internal fault usually relating to hight internal tempreture. If cooling the TCU does not fix the error please contact your dealer. |
| 105 | The loaded maps are a newer version than the driver software. Use older maps or update the driver to a newer software version |
| Solenoid Output 1 | |
| 112 | Resistance deviation too large, Resistance too high |
| 113,114 | Resistance deviation too large, Resistance too low |
| 116,117 | Short to ground |
| 118,128 | Short to ground Solenoid 1 or Solenoid 2 (common diagnostics) |
| Solenoid Output 2 | |
| 122 | Resistance deviation too large, Resistance too high |
| 123,124 | Resistance deviation too large, Resistance too low |
| 126,127 | Short to ground |
| 118,128 | Short to ground Solenoid 1 or Solenoid 2 (common diagnostics) |
| Solenoid Output 3 | |
| 132 | Resistance deviation too large, Resistance too high |
| 133,134 | Resistance deviation too large, Resistance too low |
| 136,137 | Short to ground |
| 138,148 | Short to ground Solenoid 3 or Solenoid 4 (common diagnostics) |
| Solenoid Output 4 | |
| 142 | Resistance deviation too large, Resistance too high |
| 143,144 | Resistance deviation too large, Resistance too low |
| 146,147 | Short to ground |
| 138,148 | Short to ground Solenoid 3 or Solenoid 4 (common diagnostics) |
| Solenoid Output 5 | |
| 152 | Resistance deviation too large, Resistance too high |
| 153,154 | Resistance deviation too large, Resistance too low |
| 156,157 | Short to ground |
| 158,168 | Short to ground Solenoid 5 or Solenoid 6 (common diagnostics) |
| Solenoid Output 6 | |
| 162 | Resistance deviation too large, Resistance too high |
| 163,164 | Resistance deviation too large, Resistance too low |
| 166,167 | Short to ground |
| 158,168 | Short to ground Solenoid 5 or Solenoid 6 (common diagnostics) |
| Solenoid Output 7 | |
| 172 | Resistance deviation too large, Resistance too high |
| 173,174 | Resistance deviation too large, Resistance too low |
| 176,177 | Short to ground |
| Solenoid Output 8 | |
| 182 | Resistance deviation too large, Resistance too high |
| 183,184 | Resistance deviation too large, Resistance too low |
| 186,187 | Short to ground |
| 188,198 | Short to ground Solenoid 8 or Solenoid 9 (common diagnostics) |
| Solenoid Output 9 | |
| 192 | Resistance deviation too large, Resistance too high |
| 193,194 | Resistance deviation too large, Resistance too low |
| 196,197 | Short to ground |
| 188,198 | Short to ground Solenoid 8 or Solenoid 9 (common diagnostics) |
